GAM - LIFTING POINT WITH RING

Swivel lifting point with ring to lift, turn and tilt loads; to be installed on the load itself through a threaded hole.

✔ Made of high strength G80 steel alloy; precision forging and heat treatment to achieve high performance.
✔  Coated with epoxy resin, to effectively prevent surface corrosion.
✔  Clear mark of WLL and thread on the lifting point body.
✔  Same load capacity in all loading direction.
✔  Orientable at 360° with tilting ring at 230°.
✔  Mounted on ball bearing to make the load orientation easier.
✔  Hexagonal design of base to make the mounting easier
✔  Tested at 100% magnaflux.
✔  Tested at 20.000 stress cycles.
✔  Alloy Steel Grade 80.

■ Wide range of load capacity (M8-M64, 0,3t-30t).
■ Safety factor 4:1.
■ Compliant to DM2006/42/EC and EN1677-1.


Not suitable for continuous rotation under load.
Never exceed published Working Load Limit (WLL).
